CR510
Cobra Elite
$65,500
List price for the configuration below.
Comes standard with
- 61" X 121" Cutting Area
- 10" Z Clearance w/ 14" of Z Axis Travel
- Fully Welded Industrial Steel Frame
- 3rd Row of Legs for a More Ridged Frame & Less Vibration
- Industrial Powder Coated Finish
- Tapped Holes in all Feet to Accommodate Leveling Feet or Casters
- Set of 6 Leveling Feet
- Standard with 10HP ISO30 HSD Automatic Tool Changer
- 10 Tool Positions w/ Tool Holders, Tool Forks, Wrench, Changing Station & Collets
- Tool Measure Switch
- Pop-Up Pins Controlled via G-Code
- Precision Ground Helical Rack & Pinion on X & Y Axes
- Industrial Grade Ball Screw on Z Axis
- Counterbalance & Motor Brake on Z Axis
- High Precision Industrial Servo Motors on all Axes
- Hiwin Industrial Linear Rails & Bearings on all Axes
- Hiwin Auto Lube System on Each Rail
- E-Stop Emergency Stop Switch
- Limit Switches on All Axes Physical & Software
- 1" Phenolic Table Surfaced Flat
- Vacuum Grid Machined with 5 Zones
- WinCNC 3.0 Control Software
- Control PC w/20" Monitor, Keyboard & Mouse
- Control Stand with Cycle Buttons & E Stop
- Wireless Control Pendant
- V-Carve PRO Design Software
- Custom Dust Boot w/ 6" Port for Dust Hose
- 2 Year Warranty (Parts & Labor)
- Lifetime technical support by phone, email and remote connection
- Power Required - 230V @ 60A
- Power Required - 480V 3PH @ 60A optional
