SR23

Stinger 1 pricing

The 2 × 3 prototyping platform in three editions: bring your own router, WinCNC with a control PC, or servos throughout with an automatic tool changer.

TruAxis Stinger 1 CNC router seen from the front left, a compact open-gantry machine over a flat cutting table.

Configurations

SR23

Maker

$9,900

List price for the configuration below.

Comes standard with

25" X 36" Cutting Area
6" Z Clearance w/ 10" of Z Axis Travel
Fully Welded Industrial Steel Frame
Industrial Powder Coated Finish
Leveling Feet
Standard Contactor 20A for Router up to 3HP, bring your own router
Precision Ground Rack & Pinion on X & Y Axes
Industrial Grade Ball Screw on Z Axis
High Precision Microstep Motors on all Axes
Hiwin Industrial Linear Rails & Bearings on all Axes
Hiwin Auto Lube System on Each Rail
E-Stop Emergency Stop Switch
Tool Measurement Plate to Easily Set Your Z Axis
Limit Switches on All Axes Physical & Software
Sealed 1" MDF Table Top
LinuxCNC Control Software
Raspberry PI 8GB
1 Year Warranty (Parts & Labor)
Limited support, hardware only
Power Required - 110V @ 20A

SR23

Standard

$15,175

List price for the configuration below.

Comes standard with

25" X 36" Cutting Area
6" Z Clearance w/ 10" of Z Axis Travel
Fully Welded Industrial Steel Frame
Industrial Powder Coated Finish
Leveling Feet
Standard Contactor 20A for Router up to 3HP, bring your own router
Precision Ground Rack & Pinion on X & Y Axes
Industrial Grade Ball Screw on Z Axis
High Precision Microstep Motors on all Axes
Hiwin Industrial Linear Rails & Bearings on all Axes
Hiwin Auto Lube System on Each Rail
E-Stop Emergency Stop Switch
Tool Measurement Plate to Easily Set Your Z Axis
Limit Switches on All Axes Physical & Software
Sealed 1" MDF Table Top
WinCNC 3.0 Control Software
Control PC w/20" Monitor, Keyboard & Mouse
V-Carve PRO Design Software
1 Year Warranty (Parts & Labor)
Lifetime technical support by phone, email and remote connection
Power Required - 110V @ 20A

SR23

Pro

November 2026

Starting at $22,500

Starting price. Final configuration varies.

Everything in Standard, plus:

Servos on every axis, with two Y servos
Yaskawa and WinCNC precision tuning
Speed upgrades
Automatic tool changer
ODO head
Fourth axis

Lifetime technical support covers the original owner only. It is technical support by phone, email and remote connection. It is not a warranty and does not cover parts; the warranty term for each configuration is listed above.

Options

Stinger 1 options and list prices
Option	List price
T-slot table	$350
1.7 kW HSD spindle with Yaskawa VFD	$2,950
Oneida Dust Deputy 2.5	$139.95
BlackBox Storm vacuum	$2,225
Cart, sold separately	$450
Additional options available on request	Call 470.200.3459

List prices for the configurations shown. Options, freight, installation and final configuration change the price. Confirm current pricing with our team.

Configure a Stinger 1

Tell us what you make and we will quote the configuration that fits the work.
